Features
- Recommended for
Water sourced from municipal corporations, having low TDS, which does not taste salty.
- Unique e-Boiling+
Ensures that every drop of water is as pure and safe as water that has been boiled for over 20 minutes.
- Smart Auto Fill
. Ensures water is filled automatically in the storage tank thereby ensuring purified water on tap all the time.
- Mineral Guard technology
Micro-controller based electronic impulse producer prevents scaling on the quartz glass tube of UV reflector housing and keeps your water purifier functioning effectively.
- Large Storage Capacity
It comes with an 8-litre in-built storage tank. Thereby ensuring purified water on tap, all the time.
Installation and Warranty:
- Installation – Free Standard Installation is provided. The Product
is installed by a trained technician after delivery of Products. When you buy from
you do not need to place an Installation
request separately. In the rare event that you need to place an installation request
you can do so conveniently Request Installation.
- Warranty – The Goods are warranted against defects arising from
faulty designs, workmanship and materials for 12 months from the date of Installation
or 15 months from the date of sale, whichever is earlier subject to the
Terms
and Conditions applicable.
Purchase Guidance
- RO Purifiers should be used where the TDS levels in Water are high. Usually water
drawn from Borewell has high TDS leading to a salty or brackish taste.
- UV water purifiers are ideal for areas where the water does not have high TDS. Usually
water sourced from Rivers & Lakes supplied by Municipal Corporations has low TDS.
This water does not taste salty or brackish.
Technical Specifications
| Purifying Technology |
Ultra Violet (UV) |
| Applicable TDS Range in Input Water |
1- 200 mg/litre |
| Recommended for |
Municipal/Corporation/Sweet tasting water |
| Filtration / Purification Modules |
Clarity Cartridge, Chemi block, Mineral Guard, UV chamber |
| Installation Type |
Table Top and Wall Mounting |
| Purified Water Flow Rate* |
25 litre/hour |
| Storage Tank |
8 Litres |
| Dimensions (W X D X H) in mm |
320 X 275 X 410 |
| Net weight |
5.9 Kg |
| Operating/Input Voltage |
230 V AC/50HZ |
| Power Rating/Consumption |
16 Watts |
| Ultraviolet Lamp |
11 watts |
See more Technical Specifications
| Life of UV Lamp |
5000 burning hours |
| Booster pump voltage |
N/A |
| Input Water Pressure (max) |
2.0kg/sq.cm |
| Input Water Pressure (min) |
0.4 kg/sq.cm |
| Input Water Temperature |
10°C - 40°C |
| Input Water Chlorine |
0.2 mg/litre (max.) |
| Input Water Iron |
0.3 mg/litre (max.) |
| Input Water Turbidity |
15 NTU (max.) |
If the pressure is higher than the maximum specified, use of a pressure reducing valve is recommended. This accessory is available with our company at an additional cost.
* Flow rate depends on the input water pressure and condition of the filters.
Note: Technical Specifications are subject to change without prior notice.
Technology
UV Technology
This technology uses ultra violet rays to boil and purify the water. The water thus derived is safe and made free from all disease-causing micro organisms. The water treated by UV technology has all the benefits of boiling water for 20 minutes in less than a minute. Moreover it also rules out the possibility of recontamination, which always exists while cooling and handling, when boiling water manually.
UV technology treats water in 3 stages.
- First being filtration of suspended particles like dust, rust and mud up to 5 microns.
- In the next stage the technology enables itself to absorb organic impurities, foul smell & taste, lead, pesticides and VOCs.
- Later in the third and final stage, the ultra violet rays deactivate bacteria, virus, protozoa including cyst and other disease-causing micro-organisms.
- The entire purification process is natural and free from chemicals and also retains the natural taste of water and all essential minerals required, making the water consumable.
Aquaguard Advantage
- Trusted by
15 million mothers and owned by 162,000 doctors
- Service
Across more than 500 towns
- Installation
Free Standard Installation
- Certified by
More than 110 national and international leading labs
- After sales service
100% service centers within a 5 km radius
- Awards
Super Brand, Water Digest Award, Readers Digest trusted brand
- Endorsed By
Indian Medical Academy
