Access Control Systems

Description

n how many ways can you protect your crucial data from miscreants? Choose the authorised access cards which are identified by the Access Control System. As a controller, you can open the door using your authorised access card. But if there is an attempt to access it in an unauthorised way, it sends out a beep to alert the authorities. Moreover, its anti-pass back restricts the entry of people after you and ensures complete safety. It also generates reports of entry and exit of each person along with time and areas accessed.

Features

  • Controller Panels
    These panels are available in 2 door and 4 door options.
  • Door Access
    It can provide access control for any number of doors.
  • Access Cards
    A single controller can handle up to 9999 access cards.
    Can Provide selective Access to Certain Restricted Areas.
    Access Can Be Gained Through Proximity Card or Biometric Reader (Finger Print) .
    Can Integrate Time Management/Attendance System.

Technical Specifications


Note: Technical Specifications are subject to change without prior notice.

Devices

PROXIMITY CARDS
  • Frequency 125KHZ

lease Note: This device is not a part of the Standard Package. Available as an accessory at an additional cost.


Operating temp -30 to 55 degree

Note: Technical Specifications are subject to change without prior notice.


Note: Technical Specifications are subject to change without prior notice.

ELECTROMEGNETIC DOOR LOCKS
  • Dual voltage selectable (12VDC or 24VDC)
  • Green/Red LED indication of lock Status
  • Anodized Aluminum Casing
  • Anti Tamper Jam nuts

  • Voltage: 12VDC / 24VDC
  • Current Draw: 12V/500mA /12V 250mA
  • Dimensions : Magnet - (L)250x(W)42x(T)25 mm
  • Armature - (L)180x(W)38x(T)11 mm

    • Note: Technical Specifications are subject to change without prior notice.


CONTROLLER
  • It is the main processing unit
  • Stand Alone or Networking System
  • Built In Anti Tamper Protection / Buzzer
  • Advanced Programmable Functions for different levels within the groups to maximise managent control
  • Supports multiple proximity, keypad, biometric, smart card and RS485
  • Capability of connecting external backup power supply for emergency



  • Door Control : 2 Doors
  • No. of Reader 4 ( 2 In / 2 Out)
  • Capacity of records : 4200
  • No. Of Cards : 9999
  • Keypad : 16 Keys
  • LED Indicator : 8 Keys
  • Input Voltage : 8V - 24 V DC
  • Dimensions ( W X H X D) in mm : 137 X 180 X 54

Note: Technical Specifications are subject to change without prior notice.
CARD READER
  • It reads the credentials from an access card and allows access through control points, typically a locked door.
  • Built In Beeper
    • Built in Tamper Switch

  • Read Range : 5 cm - 15 Cm
  • Dimensions (W X H X D) in mm : 75 X 11.5 X 16 D

Note: Technical Specifications are subject to change without prior notice.
